Ansys Maxwell

Electromagnetic Field Simulation for Electrical Devices

Advanced EM Simulation for Electrical Machines, Transformers, and Actuators

Ansys Maxwell is a leading electromagnetic (EM) field simulation software for low- and high-frequency electromagnetic devices. It is widely used for designing, analyzing, and optimizing electric motors, transformers, sensors, actuators, and other electromechanical components, helping engineers achieve high performance, efficiency, and reliability.

Get a Quote
Get a Free Consultation

Ansys Maxwell provides a comprehensive platform for 2D and 3D electromagnetic field simulation using finite element analysis (FEA). It allows engineers to predict electromagnetic behaviour, forces, torque, and losses in electrical devices. Maxwell integrates seamlessly with other Ansys tools for Multiphysics simulations, including thermal, structural, and motion analysis.

What’s in it for Engineers

Electromagnetic Field Simulation: Maxwell provides precise 2D and 3D simulations of electromagnetic fields, enabling engineers to design and optimize electric motors, transformers, and actuators with high accuracy.

Motor and Electromagnetic Drive Optimization: Engineers can simulate and optimize motor performance, reducing prototyping costs and improving efficiency for applications in automotive, industrial machinery, and consumer products.

Electromagnetic Compatibility (EMC) and Noise Reduction: Maxwell helps engineers predict and mitigate electromagnetic noise and interference, ensuring EMC compliance and reducing the impact of electromagnetic noise on system performance.

Advanced Materials and Thermal Analysis: The tool supports the integration of thermal analysis with electromagnetic simulations, helping engineers improve heat management in electromechanical systems, thus enhancing longevity and efficiency.

2025_12_03_18_58_06_999_862894

Featured Applications


Ansys Maxwell is an advanced tool for electromagnetic field simulations, designed to optimize electric machines, motors, transformers, and other electromagnetic systems.

Electric Motor Design & Optimization

AC & DC Motors: Design and optimize performance for AC and DC motors in industrial systems.

Motor Efficiency: Minimize energy losses and improve torque and power density.

Motor Drives Integration: Analyze the interaction between motors and drives for better control.

2025_12_03_19_02_28_594_968224

Permanent Magnet Motors

High-Efficiency Motors: Design permanent magnet synchronous motors (PMSM) for electric vehicles (EVs) and industrial applications.

Motor Torque & Speed Control: Optimize torque and speed characteristics for different operational conditions.

Thermal Management: Ensure optimal cooling and minimize heat-related issues in high-performance motors.

2025_12_03_19_04_22_538_520029

Transformer Design & Performance

Power Transformers: Simulate core losses, magnetic fields, and flux distribution to optimize transformer design.

Leakage Flux Analysis: Identify and reduce leakage flux to improve efficiency.

Short-Circuit & Fault Simulation: Model short-circuit conditions for transformer protection and reliability.

2025_12_03_19_09_41_849_200997

Power Electronics & Inverter Design

Switching Converters: Simulate and optimize power electronic converters for maximum efficiency.

Inverter Design: Analyze inverter performance, minimizing harmonics and losses in power conversion.

Motor Drives: Optimize motor drive systems to ensure efficient power delivery and control.

2025_12_03_19_11_33_252_734918

Electromagnetic Interference (EMI) & EMC

EMI Shielding: Design shielding solutions to mitigate electromagnetic interference and improve device reliability.

Conducted & Radiated EMI: Simulate both conducted and radiated EMI to meet regulatory standards.

Signal Integrity: Ensure minimal distortion and signal loss in high-frequency systems.

2025_12_03_19_13_18_607_105200

Electric Vehicle (EV) Motors

EV Motor Design: Optimize motor designs for electric vehicles, ensuring high torque and energy efficiency.

Battery Integration: Model the interaction between electric motors and batteries for better range and performance.

Thermal Management: Simulate and optimize cooling systems for motors and battery packs in EVs.

2025_12_03_19_15_13_006_611389

Inductor & Coil Design

Power Inductors: Optimize inductors for power supplies and energy storage systems to minimize losses.

Coil Geometry Design: Design coil shapes and sizes for efficient electromagnetic performance.

Magnetic Saturation: Simulate and mitigate magnetic saturation effects in inductive components.

2025_12_03_19_16_51_448_352742

Magnetic Sensors & Devices

Magnetic Field Sensors: Design and optimize magnetic sensors for precise measurements in industrial applications.

Hall Effect Sensors: Simulate and improve Hall effect sensors for automotive and consumer electronics.

Actuators: Optimize electromagnetic actuators for use in robotics and automation.

2025_12_03_19_19_13_338_917799

Aerospace & Defense Motors

Motors for Aerospace: Design reliable motors and actuators for aerospace applications under extreme environmental conditions.

Actuator Design: Simulate electromagnetic actuators for control systems in aerospace and defense applications.

Radar & Antenna Systems: Optimize radar and antenna designs for improved performance and sensitivity.

2025_12_03_19_21_03_622_299845

High-Frequency Electromagnetic Systems

Microwave Components: Design and optimize components like filters, antennas, and resonators for microwave and RF systems.

Radar Systems: Simulate electromagnetic field distribution in radar systems to optimize sensitivity and range.

Wireless Communication Devices: Analyze and improve performance in wireless devices by minimizing electromagnetic interference.

2025_12_03_19_22_44_784_478465

Relevant FAQs

Can Ansys Maxwell simulate electromagnetic fields? +

Yes, it specializes in 2D/3D electromagnetic field simulations for electrical devices.

Does Maxwell support motor design? +

Yes, it is commonly used for designing and optimizing electric motors, transformers, and actuators.

How does Ansys Maxwell handle magnetic field analysis? +

It accurately simulates magnetic field behavior in static and dynamic conditions.

Can Maxwell model thermal effects in electrical systems? +

Yes, it integrates with thermal simulations to evaluate temperature effects on electrical devices.

Does Maxwell support high-frequency applications? +

Yes, it provides high-fidelity simulations for RF and microwave components.

How does Maxwell optimize motor efficiency? +

It simulates and optimizes motor design to improve efficiency and performance.

Can Maxwell be used for coil design? +

Yes, it offers detailed simulations for coil design and optimization in inductors and transformers.

Which industries benefit most from Maxwell? +

Automotive, industrial automation, aerospace, consumer electronics, and energy sectors.

Who should use Ansys Maxwell? +

Electrical engineers, motor designers, sensor developers, and R&D teams working on electromagnetic devices.
