Ansys Motor-CAD

Advanced Electric Motor Design and Thermal Analysis Software

Motor-CAD is a specialized software platform for the design, analysis, and optimization of electric motors. It enables engineers to accurately predict electromagnetic, thermal, and mechanical performance, ensuring high efficiency, reliability, and compact design. Motor-CAD is widely used in automotive, industrial, aerospace, and robotics applications where electric motor performance is critical.

Get a Quote
Get a Free Consultation

Motor-CAD provides a comprehensive suite of tools to simulate motor performance, thermal behaviour, and electromagnetic efficiency. It integrates seamlessly with other Ansys products for Multiphysics analysis and offers fast, accurate results for design iteration, optimization, and validation. Motor-CAD is suitable for all types of motors including induction motors, permanent magnet synchronous motors (PMSM), and switched reluctance motors.

What's in it for Engineers

Motor Design Optimization: Motor-CAD allows engineers to simulate and optimize electric motor performance for various applications, ensuring maximum efficiency, torque, and power density while minimizing energy consumption.

Thermal and Loss Analysis: Engineers can assess thermal performance and identify losses (e.g., core, copper, and iron losses), enabling more efficient designs that can handle heat better and operate at lower temperatures.

Multi-Physics Integration: With integrated electromagnetic, thermal, and mechanical simulations, Motor-CAD provides a holistic approach to design, improving motor performance and reducing time-to-market.

Fast Iterative Design: Motor-CAD's specialized motor design tools enable engineers to

2025_12_03_19_40_29_213_448149

Featured Application

Ansys Motor-CAD helps engineers design and optimize electric motors by integrating electromagnetic, thermal, and mechanical simulations.

Electric Motor Design & Optimization

Motor Performance: Model and optimize motors for key metrics like torque, efficiency, and power density.

Efficiency: Simulate conditions to enhance motor efficiency and reduce energy losses.

Multi-Physics: Integrate electromagnetic, thermal, and mechanical analysis for a balanced design.

2025_12_03_19_37_17_437_587187

Thermal Analysis for Motor Design

Temperature Distribution: Simulate motor temperature to prevent overheating and improve reliability.

Cooling Optimization: Design and test cooling systems to maintain motor performance.

Thermal Stress: Analyze thermal stress to avoid issues related to material expansion.

2025_12_03_19_42_18_920_184442

Electromagnetic Design and Simulation

Field Analysis: Simulate the motor’s electromagnetic field for optimal flux distribution.

Magnetic Saturation: Model and minimize magnetic saturation for better efficiency.

Design Iteration: Quickly modify designs using electromagnetic simulations.

2025_12_03_19_44_10_700_217173

Motor Control & Drive System Simulation

Drive System Integration: Simulate motor interactions with power electronics for better drive performance.

Control Algorithms: Test motor control algorithms to improve speed and torque regulation.

Inverter Compatibility: Optimize motor and inverter integration for efficient power delivery.

2025_12_03_19_46_12_072_776210

Thermal-Electromagnetic Coupling

Coupled Simulations: Analyze both thermal and electromagnetic effects to optimize performance.

Heat Losses: Minimize heat losses in key motor components like the stator and rotor.

Material Selection: Use thermal simulations to select materials that handle heat better.

2025_12_03_19_48_03_964_144616

Vibration & Mechanical Stress Analysis

Vibration Simulation: Model vibrations to ensure stable motor performance.

Stress Distribution: Simulate stress and strain in motor components to prevent failure.

Rotor & Shaft Design: Optimize rotor and shaft to reduce wear and improve longevity.

2025_12_03_19_49_48_665_169339

Motor Sizing and Customization

Quick Sizing: Use sizing tools to calculate motor parameters before detailed design.

Custom Design: Tailor motor designs for specific applications like automotive or robotics.

Scalability: Scale motor designs for different power outputs and sizes.

2025_12_03_19_51_24_916_902639

Noise, Vibration, and Harshness (NVH)

NVH Analysis: Model noise and vibration to improve motor performance and comfort.

Acoustic Optimization: Reduce noise in motors used in vehicles and appliances.

Vibration Control: Minimize vibrations to avoid damage in high-vibration environments.

2025_12_03_19_53_09_247_380162

High-Speed & High-Temperature Applications

High-Speed Motors: Design motors for high-speed applications like aerospace and automotive.

Thermal Resistance: Optimize designs to handle high temperatures without losing performance.

Critical Systems: Focus on motors for applications requiring high reliability.

2025_12_03_19_55_54_421_733941

Advanced Optimization Tools

Multi-Objective Optimization: Balance efficiency, size, cost, and performance through optimization.

Topology Optimization: Optimize motor geometry to reduce weight and material use.

Design Exploration: Test multiple design alternatives to find the best solution for performance goals.

2025_12_03_19_57_44_289_658763

Relevant FAQs

Can Motor-CAD simulate motor thermal performance? +

Yes, it simulates both thermal and electromagnetic performance in motors, optimizing heat dissipation.

Does Motor-CAD optimize motor efficiency? +

Yes, it optimizes motor design for efficiency, performance, and thermal management across various motor types.

How does Motor-CAD handle different motor technologies? +

Motor-CAD supports synchronous, induction, and permanent magnet motors for multi-technology optimization.

Can Motor-CAD be used for hybrid and electric vehicle motors? +

Yes, it supports simulation and optimization of motors used in electric and hybrid vehicles.

How does Motor-CAD help with motor cooling design? +

It integrates thermal modeling with electromagnetic simulations to design effective cooling strategies.

Can Motor-CAD model losses in motor systems? +

Yes, it accurately calculates core, copper, and iron losses under various operating conditions.

Does Motor-CAD integrate with other Ansys tools? +

Yes, it integrates with tools like Ansys Maxwell for more detailed electromagnetic simulations.

Which industries benefit most from Motor-CAD? +

Automotive, EV, aerospace, industrial automation, consumer electronics, and renewable energy sectors.
